Linear Axis
EZ-2352-066 | Key Features
- Slide 90 x 66 mm (L x W)
- Payload up to 4 kg
- Incremental Measuring System
- Dynamic Linear Motor with up to 2,5 m/s
- High Positioning Accuracy
- Compact Design
Downloads
Product description
Highly integrated construction and compact design make the axis versatile for high-precision positioning tasks with limited installation space. Despite its compactness, the axis offers good load capacities and tilting moments. It can also be installed in upright position or lying on its side. The linear axis is designed for small to medium-sized strokes with loads up to 30 N. The hard-coated aluminum slide is dynamically driven by a Tecnotion UC3 motor. Preload is achieved by magnet groups. The axis is equipped with an incremental measuring system from Heidenhain (LIK 21). The rail (chrome steel) is available in 2 standard lengths, deviating lengths on request.
Fields of application: Inspection technology, non-contact 2D measurement, sensor and camera positioning for inspection, electronics and PCB manufacturing, AOI (automatic optical inspection), automation processes.
In general: Applications with high demands on dynamics, precision, repeatability, smooth scan movements, short settling times.
Specifications
Type | Unit | Stroke 20 | Stroke 100 |
|---|---|---|---|
| Stroke | |||
| Positioning Accuracy uncompensated | |||
| Repeatability (bidirectional) 1) | |||
| Position Stability 1) | |||
| Vertical/Horizontal Straightness (XTZ/XTY) | |||
| Pitch (XRY) | |||
| Yaw (XRZ) | |||
| Max. Speed unloaded | |||
| Max. Acceleration unloaded | |||
Mechanical Data | |||
| Mounting Position | |||
| Dimension L x W x H | |||
| Max. Load 2) | |||
| Load Capacity vertical (Z) push/pull | |||
| Load Capacity lateral (Y) | |||
| Moment of Tilt around Y | |||
| Moment of Tilt around X | |||
| Moment of Tilt around Z | |||
| Moving Mass (slide) | |||
| Total Mass (incl. slide) | |||
Encoder | |||
| Type | |||
| Sensor Signal | |||
Drive | |||
| Type | |||
| Intermediate Circuit Supply | |||
| Continuous Force | |||
| Peak Force | |||
| Constant Current | |||
| Peak Current | |||
| Cable Length | |||
Interfaces and Environment | |||
| Air Consumption | |||
| Supply Pressure | |||
| MTBF | |||
| Limit Switch | |||
| Clean Room Suitability | |||
Drive Control | |||
| Standard | |||
| High end |
1) depending on drive control
2) large mass moments of inertia must be taken into account
Control
We offer the EZ-2352-066 with the following drive controllers:
